Clean Power Store  |  SKU: 8003223486553

NEP BDM-2000 Microinverter | High-Capacity | 4x 750W Panel Suppor | IP67 Rated

$350.00
Shipping calculated at checkout.

Shipping

1 to 2 days of handling time and 3 to 7 days of delivery

BDM-2000 Microinverter

High-Capacity | 4x 750W Panel Support | Built-in WiFi | IP67 Rated

BDM-2000 Microinverter

The BDM-2000 microinverter, developed by NEP (Ningbo Deye Inverter), is a high-capacity, globally certified microinverter designed for solar photovoltaic (PV) installations. It supports up to four 750W solar panels and features advanced monitoring with built-in WiFi.

With integrated grounding, configurable grid parameters, and a NEMA-6/IP-66/IP-67 enclosure, the BDM-2000 is ideal for both indoor and outdoor environments. It meets international standards including UL1741, IEEE 1547-2018, and California Rule 21.

Key Specifications

Key Specifications

3,000W Max Recommended PV Input

60V Max DC Open Circuit Voltage

18A × 4 Max DC Input Current

2,000W Peak AC Output

97.3% Peak Efficiency

IP67 Rated | NEMA-6 Enclosure

Built-in WiFi & PLC Communication

-40°C to 65°C Operating Temp

Product Highlights

Product Highlights

Advanced MPPT Control

Supports 4 independent MPPT channels with 99.9% tracking accuracy.

Global Compliance

Certified to UL1741, IEEE 1547-2018, Rule 21, IEC/EN 62109, CEI 021, VDE & more.

Smart Monitoring

Includes built-in WiFi and PLC for easy system performance tracking via portal and mobile app.

Robust Protection

Integrated arc-fault detection, anti-islanding, overload, and rapid shutdown support.

Ready for Scalable Solar Integration

The BDM-2000 offers peak efficiency, safety, and compatibility with global standards for residential and commercial PV systems.

Supports parallel operation with BDM-1600/1200 | Touchscreen + Web Portal Access | Built for Harsh Environments

Payment & Security

Payment methods

    Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

    • Visit our support center

      Expert help & advice

    • Check your order status

      Updates & tracking

    • Returns & exchanges

      All you need to know

    • Price-match guarantee

      Our promise to you
    Description

    BDM-2000 Microinverter

    High-Capacity | 4x 750W Panel Support | Built-in WiFi | IP67 Rated

    BDM-2000 Microinverter

    The BDM-2000 microinverter, developed by NEP (Ningbo Deye Inverter), is a high-capacity, globally certified microinverter designed for solar photovoltaic (PV) installations. It supports up to four 750W solar panels and features advanced monitoring with built-in WiFi.

    With integrated grounding, configurable grid parameters, and a NEMA-6/IP-66/IP-67 enclosure, the BDM-2000 is ideal for both indoor and outdoor environments. It meets international standards including UL1741, IEEE 1547-2018, and California Rule 21.

    Key Specifications

    Key Specifications

    3,000W Max Recommended PV Input

    60V Max DC Open Circuit Voltage

    18A × 4 Max DC Input Current

    2,000W Peak AC Output

    97.3% Peak Efficiency

    IP67 Rated | NEMA-6 Enclosure

    Built-in WiFi & PLC Communication

    -40°C to 65°C Operating Temp
    Product Highlights

    Product Highlights

    Advanced MPPT Control

    Supports 4 independent MPPT channels with 99.9% tracking accuracy.

    Global Compliance

    Certified to UL1741, IEEE 1547-2018, Rule 21, IEC/EN 62109, CEI 021, VDE & more.

    Smart Monitoring

    Includes built-in WiFi and PLC for easy system performance tracking via portal and mobile app.

    Robust Protection

    Integrated arc-fault detection, anti-islanding, overload, and rapid shutdown support.

    Ready for Scalable Solar Integration

    The BDM-2000 offers peak efficiency, safety, and compatibility with global standards for residential and commercial PV systems.

    Supports parallel operation with BDM-1600/1200 | Touchscreen + Web Portal Access | Built for Harsh Environments
