VSUN 405W 108 Mono Cells Bifacial Solar Panel | VSUN 405-132BMH
The VSUN405-108BMH is a 405 watt bifacial monocrystalline solar panel designed for superior efficiency and robustness, making it suitable for both residential and commercial rooftop applications. With 108 half-cut PERC cells, this panel reaches a module efficiency of 20.74% and offers a positive power tolerance ranging from 0 to +3%, guaranteeing steady energy production. Its bifacial construction allows for up to 30% extra energy generation from the back side, depending on the surrounding installation conditions. The panel features an elegant all-black design with a transparent backsheet. Built with a tough anodized aluminum frame and 3.2 mm tempered glass, it is rated to handle wind pressures up to 2400 Pa and snow pressures up to 5400 Pa, ensuring dependability in varied weather situations.
Key Features:
- MBB technology with Circular Ribbon
- Higher output power
- Half-cell Technology
- Positive tolerance offer
- Bifacial cells, converting more sunlight into electricity
- Better shading tolerance
- Certified for salt/ammonia corrosion resistance
- Load certificates: wind to 2400Pa and snow to 5400Pa
- Lower LCOE
Product Details:
- Mfr. Part Number: VSUN405-108BMH
- Power Output: 405 Watts
- Cells: 108 Mono Solar Cells Series Strings
- Weight: 47.18 lb
- Dimensions : 67.8 x 44.65 x 1.18 in
- Pallet Qty: 36 Pcs
- Container Qty: 828 Pcs
Specifications
Specifications:
|
Manufacturer: |
Sunergy VSUN |
|
Model: |
VSUN405-108BMH |
|
Maximum Power STC: |
405 watts DC |
|
Maximum Power PTC: |
373.5 watts DC |
|
Nominal Power NOCT: |
303.8 watts DC |
|
Module Efficiency: |
20.74% |
|
Maximum Power Voltage Vmp (V): |
31.36 Volts |
|
Maximum Power Current Imp (A): |
12.92 Amps |
|
Open Circuit Voltage Voc (V): |
37.36 Volts |
|
Short Circuit Current Isc (A): |
13.78 Amps |
|
Maximum System Voltage (IEC/UL): |
1500 VDC |
|
Maximum Series Fuse Rating: |
30 A |
|
Cells Per Module: |
108 solar cells (12×9) |
|
Cell Type: |
Monocrystalline Bifacial |
|
Frame: |
Black anodized aluminum frame |
|
Backsheet: |
Transparent black-mesh backsheet |
|
Frontside: |
AR-Coating toughened glass, 3.2 mm |
|
Dimensions: |
67.80 x 44.65 x 1.18 inches (1722×1134×30mm) |
|
Weight: |
47.18 lbs (21.4 Kg) |
|
Connector Type: |
MC4 compatible |
|
Junction Box: |
IP68 Rated, 3 diodes |
|
Operating Temperature Range: |
-40F to +185F |
|
Nominal Module Operating Temperature (NMOT): |
113 degrees F +/- 3.6 degrees |
|
Front Load (snow) Test: |
5400 Pa |
|
Rear Load (wind) Test: |
2400 Pa |
|
Hailstone impact test: |
1 inch hail at 83 km/h from 1m distance |
|
Modules per Pallet: |
36 |
|
Pallet Weight: |
N/A |
|
Fire Safety Classification: |
Class II |
|
Certifications: |
UL 61730 & CSA 61730 IEC 61215 & IEC 61730 |
|
Product Warranty: |
25-year material and workmanship |
|
Performance Warranty: |
30-year performance guarantee |
